| Model | 0.7x-400d-8 |
|---|---|
| Mag (x) | 0.7 |
| Image circle (mm) | 8 |
| FOV diagonal (mm) | 11.43 |
| WD (mm) | 400.8 |
| Resolution (um) | 16.7 |
| f/# | 17 |
| NAO | 0.02 |
| DOF (mm) | 1.8 |
| Telecentricity (<degree) | 0.1 |
| Distortion (%) | 0.15 |
| coaxial | x |
| iris | x |
| mount | c |
| camera | 1/2 |
| TTL (mm) | 582 |
| 비고 |
